  • S6-S (6S)
    S6-S (6S)
    Rated pulling force: 2kg
    System weight: 360±2%g
    Recommended propeller blade: TS23
    Applicable pipe diameter: 25mm
  • S6-S (12S)
    S6-S (12S)
    Rated pulling force: 2kg
    System weight: 360±2%g
    Recommended propeller blade: TS23
    Applicable pipe diameter: 25mm
  • S6-XL
    S6-XL
    Rated pulling force: 3.5–5.5kg
    System weight: 750±2%g
    Recommended propeller blade: TS24
    Applicable pipe diameter: 30mm
  • S8
    S8
    Rated pulling force: 5–7kg
    System weight: 1070±2%g
    Recommended propeller blade: TS30
    Applicable pipe diameter: 40mm
  • S10
    S10
    Rated pulling force: 7–11kg
    System weight: 1450±2%g
    Recommended propeller blade: TS34 & TS36
    Applicable pipe diameter: 40mm
  • S10L (TS36)
    S10L (TS36)
    Rated pulling force: 11–13kg
    System weight: 1700±2%g
    Recommended propeller blade: TS36
    Applicable pipe diameter: 40mm
  • S10L (TS43)
    S10L (TS43)
    Rated pulling force: 11–13kg
    System weight: 1700±2%g
    Recommended propeller blade: TS43
    Applicable pipe diameter: 40mm
  • S11
    S11
    Rated pulling force: 15kg
    System weight: 2200±2%
    Recommended propeller blade: TS43
    Applicable pipe diameter: 50mm
  • S11L
    S11L
    Rated pulling force: 18kg
    System weight: 2300±2%g
    Recommended propeller blade: TS43
    Applicable pipe diameter: 50mm
  • S11L
    S11XL
    Rated pulling force: 22kg
    System weight: 2750±2%g
    Recommended propeller blade: TX48
    Applicable pipe diameter: 50mm
  • S13-18S
    S13-18S
    Rated pulling force: 25kg
    System weight: 4000±2%g
    Recommended propeller blade: TX56
    Applicable pipe diameter: 50mm
  • S13-24S
    S13-24S
    Rated pulling force: 25kg
    System weight: 4000±2%g
    Recommended propeller blade: TX56
    Applicable pipe diameter: 50mm
  • S15-18S
    S15-18S
    Rated pulling force: 35kg
    System weight: 4728±2%g
    Recommended propeller blade: TX63
    Applicable pipe diameter: 60mm
  • S15-24S
    S15-24S
    Rated pulling force: 35kg
    System weight: 4728±2%g
    Recommended propeller blade: TX63
    Applicable pipe diameter: 60mm
  • S15L-24S
    S15L-24S
    Rated pulling force: 50kg
    System weight: 6300±2%g
    Recommended propeller blade: TX63
    Applicable pipe diameter: 60mm
  • D15共轴-24S
    D15-Coaxial-24S
    Rated pulling force: 55kg
    System weight: 11100±2%g
    Recommended propeller blade: TX63
    Applicable pipe diameter: 80mm
  • D11XL共轴
    D11XL-Coaxial
    Rated pulling force: 35kg
    System weight: 5050±2%g
    Recommended propeller blade: TX48
    Applicable pipe diameter: 50mm
  • D13-24S
    D13-24S
    Rated pulling force: 45kg
    System weight: 7600±2%g
    Recommended propeller blade: TX56
    Applicable pipe diameter: 60mm
  • D15L共轴-24S
    D15L-Coaxial-24S
    Rated pulling force: 80kg
    System weight: 12900±2%g
    Recommended propeller blade: TX63
    Applicable pipe diameter: 80mm
